Macchina semovente Zip 30
Moving machine Zip 30

Zip 30

Moving machine

Diesel motor
Lombardini LDW 1003 hp 24
Lombardini LDW 1404 hp 33
Perkins 403D-11 hp28 diesel
Perkins 404D-15 hp35 diesel

Traction
Hydrostatic on 2 or 4 wheels.
On request: hydraulic motor with variable cylinder capacity electrically controlled.

Gears
2 gears + neutral in central posotion - electrical control from control panel.

Steering
with hydraulic power steering on the front wheels
• Indipendent steering on the rear wheels (only 4 WD)
• with 3 position selector indipendent and/or combined on request

Speed
min 0 km/h max 15 km/h

Brakes
hydraulic on the rear wheels-parking/negative brake
on 4 wheels-on request: (hydraulic brakes in 4 wheels)

Fruit collector
One central collector with idraulic lift
(available size and vertical lift rails can be seen in the diagrams shown below)
Detachable footguard.

Front lift
Hydraulic lift for loading crates up to 500 kg capacity

Rear lift
Hydraulic motor for unloading crates up to 500 kg capacity

Roller rails for crates
Over the entire length of the machine.

Pruning equipment
C.500/C.600 lt compressor - electromagnetic coupling, control on panel

Total capacity of the machine q.li 60

Measures

Measures Zip 30
